Precision Sheet Metal Fabrication Services
Fabco Manufacturing, Inc. offers precision sheet metal fabrication for industries ranging from furniture to defense. At our ISO 9001:2008 certified facility we employ modern turret punch presses and brake presses to manufacture small and medium components, and meet MIL-I-45208A inspection system requirements. Fabrication processes include but are not limited to punching, forming, shearing, laser cutting, and grinding. We also offer expert welding including TIG and Heli-Arc. We work with a range of materials including cold and hot rolled steel, stainless steel, aluminum, and brass, all of these in forms such as coil, sheet, bar stock, tubing, and plate. Our capabilities can accommodate a wide range of finishes including chrome, dip brazing, and powder coat as well as custom finishes.
We can work with materials up to 8’ in length, 3’in width, and 2’ in height, in thickness up to .25”, and up to 75 lbs.
Our press can produce pressure up to 130 tons, while holding to tolerances of ±.002” to ±.005”. Specializing in prototype to high production volumes with typical turnaround times of 2 – 4 weeks, with a 1 week “quick turn” lead time available. All of our products and processes are held to the highest industry standards. Our customer-centric approach includes a dedicated rep and access to our engineers. We are prepared to custom design a project or re-design existing product lines for better performance and cost effectiveness. For more information about sheet metal fabrication or the many value added services we offer please see the table below or contact us directly.
Additional Services
Prototypes to Kanban
Fabco has abilities ranging from being your prototype house to an external Kanban supplier. We have successfully implemented Kanban and dock to stock programs with several of our customers.
High Volume Outsourcing
Through alliances with suppliers in low-cost regions, Fabco becomes your full service vendor for low cost, high volume precision sheet metal and machined parts.
Assembly and Kitting Services
Fabco offers light assembly and kitting services. We have successfully implemented programs for our customers who have realized a significant savings when having Fabco perform these services.
Engineering & Design Services
Fabco can assist clients in designing products for optimum manufacturability. Our in-house design and manufacturing engineers offers complete design concept engineering services. Our capabilities include generating drawings and models in; Solid Works, PRO-E and AutoCAD Software.
Custom Sheet Metal Fabrication - Examples of Our Work
- Metal Fabrication of Hybrid Solar Aluminum Energy Collectors
- Metal Fabrication, Assembly & Order Fullfillment of Cold Rolled Steel Exercise Equipment
- Custom Metal Fabricated Cold Rolled Steel Lateral Filing Cabinets
- Precision Metal Fabrication of Stackable Anechoic Enclosures
- Reverse Engineered & Custom Fabricated Medical Hematology Device
- Metal Fabrication of Steel Interactive Touchscreen 3D Kiosks
- Custom Steel Fabricated Medical Photo-Acoustic Devices
- Custom Metal Compartment Fabrication
Sheet Metal Fabrication Capabilities
| General Capabilities | Small Components Medium Components Outsourcing |
| Fabrication Methods Available | Punching Forming Shearing Grinding Finishing Welding Hardware Insertion Cut-Off Machining Programming/Design Laser Cutting |
| Welding Services | MIG TIG Heli-Arc Spot |
| Equipment | Turret Punch Presses Brake Presses |
| Press Capacity | Up to 130 ton |
| Raw Material Forms | Coil Sheet Bar Stock Tubing
Plate |
| Materials | Cold Rolled Steel (CRS) Hot Rolled Steel (HRS) Stainless Steel Aluminum Brass Bronze Copper Polycarbonate Lexan |
| Finishes | Anodizing Chromate Chrome Dip Brazing Heat Treat Nickel Paint Powder Coat Silk Screening Zinc Custom |
| Material Thickness | Up to .25 in. |
| Length | Up to 8 ft. |
| Width | Up to 3 ft. |
| Height | Up to 2 ft. |
| Weight | Up to 75 lbs. |
| Hole to Hole Tolerance | ± .002 in. (<24”) ± .005 in. (>24”) |
| Hole Diameter Tolerance | ± .002 in. (<1”) ± .005 in. (>1”) |
| Angular Tolerance | ± 3 minutes |
| Fabricated Products | Lateral File Cabinets Electronic Cabinets Medical Device Shox-Box Hybrid Solar Energy Collector Electronic Enclosure Laser Medical Chassis / Tower Luggage Compartment Baggage Enclosure |
| Inspection | Coordinate Measuring Machine (CMM) Grade A Surface Plates Final Inspections First Article |
| Testing | Surface Hardness |
| Quality Assurance | Statistical Process Control (SPC) Quality Control Manual Workmanship Standards Manual |
| Additional Services Provided | Engineering Design Assembly Kitting Warehousing |
| Production Volume | Prototype to High Volume High Volume Outsourcing |
| Typical Lead Times | 2 to 4 weeks (Standard) 4 to 6 weeks (New Parts) 1 week (Quick Turn) Kanban Programs Dock to Stock |
Additional Information
| Industries Served | Contract Manufacturers Medical Computer Furniture Capital Equipment Manufacturers Consumer Goods Electronics Military Test Equipment |
| Industry Standards Met | ISO 9001:2008 Certified MIL-I-45208A Approved MIL-STD-120 ANSI/NCSL 540-1-1994 ANSI/ASQC Z1-4-1996 |
| Efficiency | Lean Manufacturing Continuous Improvement |
| RMA Rate | 0.5% (99.5% accepted) |
| File Formats Accepted | AutoCAD SolidWorks Pro/ENGINEER (Pro-E) IGES STEP DWG DXF Fabricam Fabriwin) |
